#2 Lion Chain (115 lb work load)
- 200 ft roll
Safety Snap Hooks - 2” - pkg of 25
- pkg of 100
JL-0800-XX
JL-0800-SH
JL-0800-SH-B
TruTemp Thermostat (24 Vac - 3-Wire)
True comfort control for radiant heating systems -
senses and averages ambient and radiant
temperatures.
Occupancy sensor with auto set-back of 9°F (5°C).
Do not use in wet or corrosive environments
JM-0150-XX
Low Voltage Digital Thermostat
(24 Volts - °F or °C selectable)
Not for use in corrosive or wet environments
JS-0569-WR
For P40U-P, -W, -IP, -IW: Wet Environments
Moisture Proof Thermostat - NEMA 4X
SPDT Line Voltage
40° - 110°F (5° - 40°C)
Both °F & °C Scales
Voltage: 24 - 277 Vac
Differential: 3°F
Stainless Steel Bulb
UL Listed
JS-0570-XX
Multiple Heaters per 24V Thermostat
Relay Switch: One required for each burner after
the first burner in a zone (1st burner connects to
24V thermostat)
Refer to wiring diagram Page 26
(field installed at or in burner)
NOTE: FENWAL DSI has built in relay for blower
operation
JS-0568 –CC
Line Voltage Thermostat:
Dual Scale: °F or °C
Use of line voltage thermostat disables post-purge
feature of the ignition control.
Not for use in corrosive or wet environments
JL-0772-XX
