MODEL
RECOMMENDED
MOUNTING
HEIGHT RANGE*
ft
(m)
MAXIMUM
DISTANCE
BETWEEN
HEATERS
ft
(m)
DISTANCE – OUTSIDE WALL
TO HEATER LONG AXIS
(PARALLEL TO WALL) IN “FEET”
HORIZONTAL
REFLECTOR
MOUNT
ft (m)
REFLECTOR
ANGLE
MOUNTED
UHE / EIH 200
20 – 40
(6 - 12)
50
(15)
17 – 25
(5 - 8)
COMBUSTIBLE
CLEARANCE
BEHIND
(refer to Table 1
& Figure 1)
UHE / EIH 160
18 – 30
(5 - 9)
45
(14)
15 – 20
(5 - 7)
UHE / EIH 130
16 – 25
(5 - 8)
40
(12)
15 – 20
(5 - 7)
UHE / EIH 90
14 – 22
(4.3 - 6)
30
(9)
12 – 16
(4 - 5)
UHE / EIH 60
12 – 20
(3.6 - 5.5)
25
(8)
11 – 15
(3.4 - 5)
TABLE 2 GUIDELINES FOR HEATER PLACEMENT - SPACE HEATING
IMPORTANT: Single or multiple heater placement must be such that continu-
ous operation of heater(s) will not cause combustible material or materials in
storage to reach a temperature in excess of ambient temperature plus 90F°
(50C°).
It is the installer’s responsibility to ensure that building materials with a
low heat tolerance which may degrade at lower temperatures are pro-
tected to prevent degradation. Examples of low heat tolerance materials
include vinyl siding, fabrics, some plastics, filmy materials, etc.
Refer to “Clearance to Combustibles” information on pages 6 to 8, and
Figure 1 and Table 1.
*
RECOMMENDED MOUNTING HEIGHTS are typical to provide optimum comfort in general
space heating applications. Variance to these typical heights can occur in some applications:
Higher mounting heights due to structure or application requirements
Lower mounting heights for area or ‘spot’ heat, or in areas with greater infiltration losses
(near overhead doors, etc)
