This manual contains important information as well
as DANGERs, WARNINGs and SAFETY
INSTRUCTIONs regarding the proper installation,
effective use and maintenance of the SCHROTH
harnessbelt. Please be sure to read and thoroughly
understand its contents before beginning
installation and before using the system. Follow all
instructions and Safety Instructions carefully and be
especially sure to heed all Dangers and Warnings.
Always keep this manual in your car for reference
and be sure to leave it with the car if you sell it with
the harness belt system installed.
Important information and instructions in this
manual are shown:
DANGER deals with important points about
installation of the SCHROTH harnessbelt. Ignoring
these warnings will create serious danger which
can lead to serious personal injury or death.
WARNINGS deal with important issues about installation,
use, misuse or modification of the
SCHROTH harnessbelt.
Ignoring these Warnings will significantly reduce the
performance of the harness belt system. This can result
in serious personal injury or death during an accident.
• Safety Instructions contain important hints to help you
effectively install, use and maintain the SCHROTH
harnessbelt.
Always carefully read and follow the information in
this manual, especially those highlighted as above.
If you cannot pull out webbing from the
retractor or if the retractor appears
permanently blocked –
Is the ignition is switched on?
Refer to Troubleshooting Diagram 5
[TSD 5] on page 36.
INSTALLATION ACCESSORIES
Color key:
black=0, blue=1, red=2, yellow=3, purple=5, green=8
The X in PINs must be substituted by the color key of the color you want to order!
Shoulder belt pads, pair of
black with yellow flock printing 00109
Shoulder belt pads, pair of blue with black flock printing 01109
red, yellow, purple, green with black flock printing 0X109
Shoulder belt pads, pair of black with grey flock printing 09109
Shoulder belt pads, pair of silvergrey w. black flock printing 09209
Shoulder belt pads, pair of black with black flock printing 09309
Adjusting grips for length adjuster, 4 pcs./package 00092
"Switch off" for manual lock of inertia reel 00096
SPARE PARTS
Adapter for installation at anchor point "D"
01103
(refers to index Y) of Certified Vehicle List (Vehicle Reference List))
Retractor with webbing black 01170
blue, red, yellow, purple, multicolor 0117X
Side belt black 01120
blue, red, yellow, purple, multicolor 0112X
Sensor including installation kit 01090
Wire kit including fuse 00098
Installation kit for harness belt
(w/o Sensor incl. installation kit and wire kit incl. fuse) 01097
Cover for adjuster inclusive retainer 01084
Slide cover and spring for separation buckle 00087
Operating- and Installation Instructions EA 4.3
Transparent interior sticker W26ST
