The lightest snap in bracket available anywhere on the market. This bracket
features a threaded collar that locks around either an Eyebolt or B23B Bolt-in
Bracket. Must be Sewn in – there are no wraps that work with this piece.
IMPORTANT: while this may look like something you can buy at your local
hardware store it isn’t! It is a highly specialized bracket that is built to with-
stand the extremely high forces generated by impacts!
Part Number ?
Locations Lap, Sub
Webbing 3”
Approvals FIA
Wraps N/A Must Be Sewn
WRAPPING BRACKETS
Part Number LV10
Locations Lap, Shoulder, Sub
Webbing 2”
Approvals FIA, SFI 16.1
Wrap Type Standard 3-Bar Slide
The most common bracket used in applications where 2” webbing wraps
around a bar of the roll-cage. Cans also be used in place of LV4 with a
traditional wrap where the thickness of a non-microslip wrap is too great,
or to gain a couple inches of length in the belt (standard wrap uses less
webbing than non-microslip wrap). FIA and SFI 16.1 Approved.
Part Number LV4
Locations Lap, Shoulder, Sub
Webbing 2”
Approvals FIA, SFI 16.1
Wrap Type Non Micro-slip 2-Bar Slide
This is our Most Common bracket used with Wrap in end fi ttings. It uses
a unique non micro-slip wrap to achieve greater strength than sewn end
fi ttings. Can also be used around bars. FIA and SFI 16.1 Approved.
Part Number LV11 NC
Locations Lap, Shoulder, Sub
Webbing 2”
Approvals FIA, SFI 16.1, SFI 16.5
Wrap Type Standard 3-Bar Slide
See LV10. LV11NC needed if you require SFI 16.5 approval. FIA, SFI
16.1 and 16.5 approved.
