PM175 Quick Start Guide
Communicating via the Internet
If you are communicating through the Ethernet port, define the IP address of your
meter on the network.
To define the IP address:
1. On the Instrument Setup tab, select Internet Site.
2. Click on the Connection tab.
3. Select the IP Address and type in the IP address of your meter.
The default IP address preset at the factory is 192.168.0.203.
4. In the Protocol box, select the communications protocol for the
TCP port. The meter can provide Modbus/TCP connections on
TCP port 502 and DNP3/TCP connections on port 20000. The
host port is set automatically as you select the protocol. Select
Modbus RTU for Modbus/TCP or DNP3 for DNP3/TCP.
5. In the Wait for Answer box, adjust the time that PAS waits for a
connection before announcing an error and the number of
retries PAS uses to receive a response from the device if
communications fail.
Input and Output Ratings
3 voltage inputs
690 V: (standard)
DIRECT INPUT - Nominal: 690V line-to-line voltage,
790V maximum; 400V line-to-neutral, 460V maximum -
Burden: <0.4 VA. INPUT USING PT - Burden: <0.15 VA
120 V: (optional)
INPUT USING PT - Nominal: 120V line-to-line voltage,
144V maximum - Burden: <0.04 VA
Voltage input terminals Maximum wire section: 4 mm2 (10 AWG)
3 current inputs
(Galvanically
isolated)
5A: (standard)
INPUT VIA CT with 5A secondary output - Burden: 2.5 to
4 mm2 (13-11 AWG) wire from CT.
Operating range: continuous 10A RMS Burden: < 0.1 VA
Overload withstand: 15A RMS continuous, 10A RMS for
1 second.
1A:(optional)
INPUT VIA CT with 1A secondary output - Burden: 2.5 to
4 mm2 (13-11 AWG) wire from CT.
Operating range: continuous 2A RMS Burden: < 0.02 VA
Overload withstand: 3A RMS continuous, 80A RMS for 1
second.
Communication
port COM1
EIA RS-485 standard Optically isolated, max. speed 115.2Kb/s
COM1 terminals 3 x Maximum wire section: 2.5 mm2 (12 AWG)
Communication
port COM1
(Optional)
Profibus Max. speed 12 Mb/s
Profibus terminals
5 x Maximum wire section: 2.5 mm2 (12 AWG) or using
terminal to DB9 converter: P/N AC0153 REV.A2
Communication
port COM2
(Optional)
Ethernet 10/100 Base T, auto adaptation speed,
Max. speed 100Mb/s
ETH connector Shielded RJ45 cable
Power Supply
(Galvanically
isolated)
120/230 V AC/DC
(standard)
85-265VAC, 88-290VDC; 50/60/400 Hz 9VA
12 VDC (optional) 9.5-18 VDC
24/48 VDC (optional) 18.5-72 VDC
Power Supply input
terminals
3 x Maximum wire section: 2.5 to 4 mm2
(13-11 AWG)
BG0456 REV.A2 13
