61 M2A Transmitter Operator’s Manual
Function Code 16: Write Registers
There are 21 registers in Function Code 16 that can be used to write to the M2A. This manual only
describes Register 16 because it can be used to reset an alarm condition. For a complete description
of Function Code 16, request Appendix C from RKI Instruments, Inc.
Register 16
Register 16 performs the same function as the ENTER button on the M2A. It is useful for remotely
silencing alarms. With the M2A in an alarm condition, bit [0] can be used to silence it.
Table 14: Register 16, Button Function
NOTE: Register 40 in Function Code 03, the remote configuration register, must be set to 1 in
order for Register 16 to work.
Parts List
Table 15 lists replacement parts and accessories for the M2A Transmitter.
Bit Value & Field
[0] ENTER (used for “Alarm Reset”)
0=Not Pressed
1=Pressed
Table 15: Parts List
Part Number Description
06-1248RK Calibration kit sample tubing (3/16 in. x 5/16 in.; specify length when ordering)
07-0033RK Cap gasket, for CSA type CO and H
2
S detector
07-0125RK Cap gasket, for ESM-01 detector
07-0203RK Rubber retaining boot for charcoal filter and for 65-2423RK-05 H
2
S detector
14-2101RK Spacer for 65-2423RK-05 H
2
S detector
18-0431RK-01 Junction box
33-7101RK Charcoal filter disk
45-6132RK Termination and group jumper
61-0140RK LEL detector, catalytic type, UL version
61-0140RK-05 LEL detector, catalytic type, CSA version
61-0190RK-CH4 CH
4
LEL detector, IR type
61-0190RK-HC HC LEL detector, IR type, propane calibration
61-0191RK-02 CO
2
detector, IR type, 0 - 5,000 ppm
61-0191RK-03 CO
2
detector, IR type, 0 - 5% volume
61-0191RK-05 CO
2
detector, IR type, 0 - 50.0% volume
