5 • Overview
GX-2003 Operator’s Manual
Chapter 2: Description
Overview
This chapter describes the GX-2003 instrument and accessories.
Instrument Description
The instrument includes the case, sensors, LCD, control buttons,
printed circuit boards, alarm LED’s, infrared communication port,
buzzers, vibrator, batteries, pump, flow chamber, and inlet filter
holder.
Figure 1: Components of the GX-2003, Front & Back
AIR
DISPLAY
(ADJ)
(SHIFT)
RESET
SILENCE
Alarm
LED
Array
Inlet Filter
Holder
Inlet Fitting
Exhaust
HC Filter
Retainer
CO Filter
Retainer
Battery
Cover
Flow
Chamber
Control
Buttons
Buzzer Openings
LCD
Tapered Rubber Nozzle
