Eagle Instruction Manual Setup Mode • 27
The number in parenthesis indicates the display increment for that
portion of the PPM range. In the example below, the PPM reading
would display in increments of:
• 5 from 0 to 100 ppm
• 10 from 100 to 1000 PPM
• 50 from 1000 to 10,000 PPM
• 250 from 10,000 to 50,000 PPM
If you entered a label other than ***, continue with step 6. If you
entered ***, go to the next section, “Setting a custom target gas label.”
6. Press the POWER/ENTER button to return to the Gas
Combinations menu.
7. To exit the Gas Combinations menu, press the SHIFT/▼ button
until the prompt is next to Channel 4, then press the SHIFT/▼
button again. The
ESCAPE message displays.
8. Press the POWER/ENTER button. The message SAVING DATA
displays, then the main menu displays.
Setting a Custom Target Gas Label
1. With the prompt next to the target gas label setting (***), press the
POWER/ENTER button. The first asterisk flashes.
2. Press the AIR/▲ and SHIFT/▼ buttons to display the desired
character. Available characters are A through Z, 0 through 9, and a
blank space.
3. Press the POWER/ENTER button to enter the displayed character.
The next character flashes.
4. Repeat steps 2 and 3 to enter the remaining characters. When you
enter the last character, the prompt flashes.
Updating the Fullscale PPM Setting
CAUTION: The fullscale PPM setting must correspond to 100% LEL for the
target gas in order for the Eagle to display accurate PPM
readings for the combustible gas channel.
1. Press the SHIFT/▼ button to place the prompt in the second line,
then press the POWER/ENTER button to update the fullscale
* * *
5 0
(
P
0
0
>
0 0 P M
1 0 5 ) 0 1 0 0 0 ( 5 ) 0
0 1 0 0 ( 1 ) 0 5 0 0 0 0 ( 5 ) 0 2
