26 • Setup Mode Eagle Instruction Manual
Updating Channel Settings
This procedure describes how to update channel settings for the
combustible gas, oxygen, and toxic gas channels.
CAUTION: Verify that the correct sensor is installed before you update a
channel’s settings.
Updating Combustible Gas Channel Settings
This section describes how to update the target gas label, set a custom
gas label, and update the fullscale PPM setting for the combustible gas
channel.
Updating the Target Gas Label
1. From the main menu, select the GAS COMBINATIONS menu
option.
2. Use the AIR/▲ or SHIFT/▼ button to place the prompt next to the
combustible gas channel (in this example CH4).
3. Press the POWER/ENTER button. The combustible gas target gas
label flashes. This indicates that this setting can now be updated.
4. Press the AIR/▲ or SHIFT/▼ buttons to display the available
combustible gas target gas labels (CH4, HEX, H2, ***, and NOT
USED
).
NOTE: Select the HEX or *** setting to have the ability to activate
Methane Elimination (see “Appendix B: Methane
Elimination” on page 57 for more information).
5. Press the POWER/ENTER button to enter the new target gas label.
A screen displays that shows the fullscale PPM setting, which
corresponds to 100% LEL, and display increments for the target
gas label you selected. If you select *** as the gas label, you must
update the fullscale PPM setting to correspond to 100% LEL for
the target gas.
C H 4
O Y
C O
H 2 S
X
>
