Retsch PP 25 User Manual
Page 23
Operating the machine
23
Fig. 11: After the pressing procedure
•
•
Pull the slide (S) out of the die tool.
Fig. 12: Inserting the pressing plate
•
Turn the spindle upwards to some degree.
•
Place the pressing plate (PP) onto the die tool.
•
Close the valve (H) by turning in a clockwise direction.
Fig. 13: Alternative ejection of the pellets
CAUTION
Risk of fingers being pinched
The (P) die tool’s basic body drops downwards as the pellets are being ejected.
S
PP
