Rt o – Retsch PP 25 User Manual
Page 18

Operating the machine
18
Fig. 5: Adapter for evacuating the die tool
NOTE
Make sure that the slide is pushed in as far as it will go. If you use the adapter (R)
for evacuating the die tool, it must protrude out of the back of the basic body.
Fig. 6: Inserting the lower pressure piece
The pressure pieces are ground and polished on one side.
•
Insert a pressure piece (O) with the ground and polished side (T) facing
upwards
.
Use an aluminium container to increase the durability of the pellets or if you have
not mixed any wax with the sample.
•
Insert an aluminium container if required.
5.5.2
Filling sample material into the die tool
•
If necessary, remove the grinding balls out of the sample material mixed with
wax.
R
T
O
