Parts Bag Contents

1 10 X 8mm hexagonal nut

1 Door locking plate

1 Door handle

4 M6 X 50 mm Bolts

23 M5 X 10 mm Bolts

1 M10 Locking Washer

1 M10 Washer

8 M5 Self-Locking Nuts

4 M6 Nuts

8 M5 Spring Washers

8 M5 Washers

4 M6 Washers

28 M6 X 15 mm Bolts

1 Screwdriver

1 Hex Nut Wrench
