PARTS LIST - PROFESSIONAL GRILL:
1 Handle
2 Handle supports
1 Warming rack
2 Cooking grills
2 Air Vents
1 Grill body
1 Crank
1 Grill door
1 Charcoal grate assembly
1 Ash pan collar
2 Air shutters
1 Left side table
1 Ash pan
1 Right side table
1 Left side drawer
1 Door frame bracket
1 Rear panel
4 Legs
1 Left side panel
1 Right side panel
1 Bottom panel
2 Doors
4 Locking casters
ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR SMOKER.
FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT:
www.brinkmann.net
FOR GRILL WARRANTY REPLACEMENT PARTS, PLEASE VISIT US AT:
www.grillpartsonline.com
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 800-527-0717.
(Proof of purchase will be required.)
3
Inspect contents of the box to ensure all parts are
included and undamaged.
We recommend two people work together
when assembling this unit.
The estimated time of assembly for this grill
is approximately 30 minutes.
The following tools are required to assemble
this Professional Grill:
• Pliers
• Phillips & Flathead Screwdrivers
• Adjustable Wrench
