Page 31

Installing the Car Seat Base and Car Seat

CHECK the security of the installation
by pulling the carry handles (Photo
G) in several directions. It should
not move more than 2.5 cm (1 in) in
any direction. If the car seat is loose,
remove the lap-shoulder vehicle belt
from the belt clips and re-install the car
seat beginning at step 5.

10. Lap-shoulder vehicle belt systems in

some vehicles have an Auto Locking
Mode which locks the shoulder portion
of the belt and keeps it from becoming
a hazard to older children or siblings.
To engage this mode (which we
recommend), pull the shoulder portion
of the belt out completely from the
vehicle, then let go. You should hear
a soft clicking sound as you allow the
belt to retract back into the vehicle.

If using a vehicle lap belt:

11. While pressing down upon the car seat,

pull on the belt tail of the vehicle lap
belt to tighten it around the car seat
(Photo H).

Installing the Car Seat: Without the Car Seat
Base

cont’d

12. Once tight, slip the vehicle belt into the

belt clip. (Photo I).

13. Slip the vehicle belt on the other side of

the car seat into the other belt clip.

14.

CHECK that the car seat is at the
proper angle. The bottom edge of the
car seat should be between 10 degrees
tipped back and horizontal after
installation (Photo J). If the bottom
edge is tipped forward, remove and
re-install the car seat, using towels to
make the car seat level.

15.

CHECK the security of the installation
by pulling the side handles in several
directions (Photo K). It should not
move more than 2.5 cm (1 in) in any
direction. If the car seat is loose,
remove the vehicle belt from the
belt clips and re-install the car seat
beginning at step 11.
