Installing the Car Seat Base and Car Seat

be visible and facing outward when
connectors are correctly routed.

5. The LATCH/UAS belt must be secured

in place by the lock-off clamp. To
secure the belt in place:

Center the colored stitch line of the

LATCH/UAS belt in the middle of
the lock-off clamp (Photo E).
Close the lock-off clamp and secure

it firmly upon the belt by flipping the
top closure down into place.

6. If the vehicle seat back is adjustable,

lock the vehicle seat back into the
upright position.

7. Center the car seat base on the vehicle

seat between the vehicle LATCH/UAS
anchorages (Photo F), making sure the
areas between the vehicle LATCH/UAS
anchorages and the areas under and
behind the car seat base are clear of
obstructions.

CHECK that car seat base is level
by looking at the level indicator. The
window in the level indicator must

be green (Photo G). If red appears in
the window (Photo H), try any of the
following:

Remove the car seat base. Position

a rolled towel under the car seat
base (Photo I), making sure the
front of the car seat base contacts
the vehicle seat. The towel should
be compressed as the StrongArm
tightens the car seat base into place.
Install the car seat base in a

different vehicle seating position.
Seek assistance from one of

the resources in the Need Help
Securing Your Car Seat and Car
Seat Base? section.

⚠WARNING⚠

Death or Serious Injury Can Occur

To prevent ejection, the car
seat base must be properly
reclined. The level indicator
in the car seat base must be
green when installed.

Installing the Car Seat Base: With LATCH/
UAS

cont’d
