Installing the Car Seat Base and Car Seat
52
52
52
52
Installing the Car Seat Base and Car Seat
53
53
53
53
⚠WARNING⚠
Death or Serious Injury Can Occur
The car seat must always be
locked in the car seat base in
the rear-facing position when
the vehicle is in motion.
Docking the Car Seat on the Car Seat Base
cont’d
G
F
E
D
the car seat into the SmartHub of the
car seat base until you hear and feel a
CLICK
(Photo C).
For increased comfort and ease of
use, the car seat can be docked onto
the car seat base from almost any
angle.
3. Once the car seat is locked into the
SmartHub, rotate the car seat until you
hear and feel another
CLICK as it locks
into the rear-facing position. The car
seat will only lock when rotated into the
rear-facing position (Photo D). Note
that it will only lock when the release
levers are not pulled.
4. CHECK that the car seat is locked into
rear-facing position by looking at the
rotation indicators on either side of the
car seat base (Photo E). If they show
red (Photo F), the car seat is not locked
rear-facing. Re-dock the car seat.
NOTE: A small amount of rotational
movement is normal, but the car seat
should not rotate out of rear-facing
position and the rotation indicators
should not be showing red.
If the rotation indicators show red with
every docking attempt, do not use the
car seat or car seat base, and contact
Orbit Baby.
5. RECHECK that the car seat is locked
into the rear-facing position by pulling
in several directions (Photo G) to
be certain it is locked. It should not
rotate out of the rear-facing position.
If it does, do not use the car seat and
contact Orbit Baby.
