DCA-500SSK — PARTS AND OPERATION MANUAL (STD)— REV. #1 (04/14/01) — PAGE 101
DCA-500SSK — ENCLOSURE #2 ASSY.
ADD THE FOLLOWING DIGITS AFTER THE PART NUMBER
WHEN ORDERING ANY PAINTED PANEL TO INDICATE
COLOR OF UNIT:
1-ORANGE
2-WHITE
3 -SPECTRUM GRAY
4 -SUNBELT GREEN
5 -BLACK
6 -CATERPILLAR YELLOW
7 -CATO GOLD
8 -RED
THE SERIAL NUMBER MAY BE REQUIRED.
ENCLOSURE #2 ASSY.
NO PART NO PART NAME QTY. REMARKS
30 0805011304 STOPPER, DOOR 1
31 0805011204 STOPPER, DOOR 1
32 0207006000 HEX. NUT 4
33 0845047104 HINGE 2
0845045004 WASHER 2
34 0845047204 HINGE 2
0845045004 WASHER 2
35 0019208020 HEX. HEAD BOLT 6
36 0845031504 CAP 4
37 0601850097 STOPPER 2
38 0021008025 MACHINE SCREW 2
39 0600500090 EMBLEM 1
40 0021106020 MACHINE SCREW 2
41 C4464200303 ROOF PANEL 1
8485960104 LINING 1
42 C4464200403 ROOF PANEL 1
8485960104 LINING 1
43 C4464200503 ROOF PANEL 1
8485960104 LINING 1
44 C4464500304 GUIDE 1
45 C4464500204 PANEL 1
8485960104 LINING 1
46 0207008000 HEX. NUT 27
47 C4464500404 PANEL 1
48 00171008020 HEX. HEAD BOLT 11
49 8485166004 COVER, ROOF PANEL 1
8485968104 LINING 1
50 0017108020 HEX. HEAD BOLT 9
51 0019208020 HEX. HEAD BOLT 30
52 0019210025 HEX. HEAD BOLT 4
53 B9114500104 DOOR POCKET 1
54 0207006000 HEX.NUT 4
