DCA250SSI/DCA250SSIU GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (01/12/11) — PAGE 99
NAMEPLATE AND DECALS ASSY. (DCA250SSIU)
NO. PART NO. PART NAME QTY. REMARKS
1-1 M5550000303 DECAL : OPERATING PROCEDURES ....................... 1 ................. M550030
1-2 M9520100603 DECAL : WARNING AUTO START .............................. 2 ................. REPLACES C9522100003
CONTROL BOX GROUP
2-1 M5551000003 DECAL : STRIPE ......................................................... 1 ................. M55100000
2-2 M9520000104 PLATE : AMMETER CHANGE- OVER SWITCH.......... 1 ................. M92000010
2-3 M9520000204 PLATE : VOLTMETER CHANGE- OVER SWITCH ...... 1 ................. M92000020
2-4 M9522000504 DECAL : CIRCUIT BREAKER ..................................... 1 ................. M92200050
2-5 M9522000704 DECAL : PANEL LIGHT SWITCH ................................ 1 ................. M92200070
2-6 M9520001404 DECAL : PILOT LAMP ................................................. 1 ................. M92200070
2-7 M9520001304 DECAL : VOLTAGE REGULATOR ................................ 1 ................. M92000130
2-8 M9520001304 DECAL : SETTING FOR OUTPUT VOLTAGE .............. 1 ................. M92020030
2-9 M9520100304 DECAL : GENERAL CAUTIONS .................................. 1 ................. M92010030
2-10 M9520001204 DECAL : HIGH IDLE ADJUST SWITCH ...................... 1 ................. M90140010
2-11 M9520001004 DECAL : DIAGNOSTIC LAMP ..................................... 1 ................. M92100030
2-12 M9520001104 DECAL : DIAGNOSTIC BUTTON ................................ 1 ................. M92000110
2-13 M9520000904 DECAL : DIAGNOSTIC SWITCH ................................. 1 ................. M92000090
ENGINE AND RADIATOR GROUP
3-1 M9500100004 DECAL : WATER .......................................................... 1 ................. M90010000
3-2 M9500000004 DECAL : OIL DRAIN PLUG ......................................... 1 ................. M90000000
3-3 M9503000004 DECAL : WARNING : ROTATING PART ....................... 2 ................. M90300000
3-4 M9503100004 DECAL : WARNING: RADIATOR CAP ......................... 1 ................. M90310000
3-5 M5551000103 DECAL : AIR BLEEDING PROCEDURE ..................... 1 ................. M5510 0010
ENGINE OPERATING PANEL GROUP
4-1 M9520001604 DECAL : BATTERY SWITCH ....................................... 1 ................. M92000160
4-2 M5550000103 DECAL : ALARM LAMP ............................................... 1 ................. M55000010
4-3 M5550000203 DECAL : OPERATING PANEL ..................................... 1 ................. M55000020
OUTPUT TERMINAL GROUP
5-1 M9520000004 DECAL : GROUND ...................................................... 1 ................. M92000000
5-2 M9520100404 DECAL : DANGER HIGH VOLTAGE ............................ 1 ................. M92010040
5-3 M9520000504 DECAL : START CONTACT ......................................... 1 ................. M92000050
5-4 M9520100503 DECAL : WARNING, ELECTRIC SHOCK HAZARD .... 1 ................. M92010050
5-5 M9520000704 DECAL : 3-PHASE OUTPUT TERMINAL .................... 1 ................. M92000070
5-6 M4550000103 DECAL : AUXILIARY OUTPUTS .................................. 1 ................. M45000010
