DCA250SSI/DCA250SSIU GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (01/12/11) — PAGE 63
CONTROL BOX ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 M5214000002 CONTROL BOX 1
2 0601809667 CURRENT TRANSFORMER 3
3 011808015 MACHINE SCREW 6
4 M7030041000Q CIRCUIT BREAKER, 800A .........................1 ................DCA250SSI
4 0601807519 CIRCUIT BREAKER, 800A .........................1 ................DCA250SSIU
4A 0601827410 BUS BAR .....................................................2 ................DCA250SSIU
5 0601820601 AUTOMATIC VOLTAGE REGULATOR 1
5A 0601806681 FUSE, 250V 8A 1
6 0027105015 MACHINE SCREW 4
7 0601842468 RESISTOR, 5W150 OHM 1
8 0027103010 MACHINE SCREW 2
9 C1274000103 CHANGE- OVER BOARD, VOLTAGE..........1 ................DCA250SSI
9 M4273000003 CHANGE- OVER BOARD, VOLTAGE..........1 ................DCA250SSIU
10 8181852104 CHANGE TERMINAL 10
11 011606025 HEX HEAD BOLT 20
12 C0277200004 TERMINAL PLATE 3
13 8181853104 CHANGE PLATE 6
14 012210020 HEX HEAD BOLT 13
15 0040010000 WASHER, LOCK 13
16 0041410000 WASHER, FLAT 13
17 012210020 HEX HEAD BOLT 13
19 0040010000 WASHER, LOCK 13
20 0041410000 WASHER, FLAT 13
21 011208030 HEX HEAD BOLT 4
22 M5261500003 SET PANEL, ELECTRIC PARTS 1
23 011008020 HEX HEAD BOLT ........................................4 ................ REPLACES P/N 0017108020
24 8981264350 CONTROLLER ............................................1 ................DCA250SSI
24 8981359690 CONTROLLER ............................................1 ................DCA250SSIU
25 C3260503104 BRACKET 1
26 011106015 HEX HEAD BOLT 4
27 0602103091 DIAGNOSTIC LAMP 1
27A 0601810244 BULB, DC28V 1
28 0601831205 DIAGNOSTIC BUTTON 1
29 0601830710 DIAGNOSTIC SWITCH 1
30 0601830746 HIGH IDLE ADJUST SWITCH 1
31 011106015 HEX HEAD BOLT 4
32 0601821370 RECTIFIER 1
33 0027104020 MACHINE SCREW 1
34 LY2DUS24VDC RELAY .........................................................4 ................REPLACES P/N 0601827655
34A PTF08A SOCKET ......................................................4 ................REPLACES P/N 0601823109
34B PYCA1 HOLDER .....................................................4 ................REPLACES P/N 0601824400
