PAGE 12 — DCA250SSI/DCA250SSIU GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (01/12/11)
Table 1. Generator Specifi cations
Model DCA250SSI/DCA250SSIU
Type
Revolving fi eld, self ventilated,
open protected type synchronous generator
Armature Connection Star with Neutral
Phase 3
Standby Output 220 kW (275 kVA)
Prime Output 200 kW (250 kVA)
Voltage — 1Ø 120,127,139, 240, 254 and 277V
Voltage — 3Ø 208, 220, 240, 416, 440 and 480V
Frequency 60 Hz
Speed 1800 rpm
Power Factor 0.8
Aux. AC Power Single Phase, 60 Hz
Aux. Voltage/Output 120VAC/4.8 Kw (2.4 kW x 2)
Sound Level dB (A)
Full Load at 23 ft. (7.0 Meters)
68
Dry Weight 8,203 lbs. (3,720 kg)/8,303 lbs. (3,766 kg)
Wet Weight 9,305 lbs. (4, 220 kg)/9,360 lbs. (4, 245 kg)/
Maximum Lifting Capacity 16,500 lbs. (7,484 kg)
Table 2. Engine Specifi cations
Model ISUZU BH6UZ1X EPA Tier 3 Certifi ed
Type
4 cycle, water-cooled, direct injection,
turbo-charged air-cooled
No. of Cylinders 6 cylinders
Bore x Stroke 4.72 in. x 5.71 in. (120 mm x 145 mm)
Displacement 600 cu. in. (9,839 cc)
Rated Output 308 HP at 1800 rpm
Starting Electric 24 VDC
Coolant Capacity 14.3 gal. (54.0 liters)
Lube Oil Capacity 10.8 gal. (41.0 liters)
Fuel Type #2 Diesel Fuel
Fuel Tank Capacity 121 gal. (460 liters)/129 gal. (490 liters)
Fuel Consumption
14.7 gal. (55.8 L)/hr at full load 10.9 gal. (41.2 L)/hr at 3/4 load
7.5 gal. (28.5 L)/hr at 1/2 load 4.4 gal. (16.6 L)/hr at 1/4 load
Battery 12V-150 Ah x 2/4D CCA 925 X 2
SPECIFICATIONS
