DCA250SSI/DCA250SSIU GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (01/12/11) — PAGE 65
CONTROL BOX ASSY. (CONTINUED)
NO. PART NO. PART NAME QTY. REMARKS
36 8972177780 SENSOR, BAROMETRIC PRESSURE ......1 ................REPLACES P/N 0602130220
37 7538070 MACHINE SCREW 2
38 8980056310 RELAY, STARTER .......................................1 ................REPLACES P/N 0602201401
39 011808015 MACHINE SCREW 2
40 8980137900 RELAY .........................................................2 ................REPLACES P/N 0602202682
41 0027105015 MACHINE SCREW 2
42 8944607061 RELAY, GLOW PLUG ..................................1 ................REPLACES P/N 0602202683
43 0027105015 MACHINE SCREW 2
44 0601515154 TERMINAL BLOCK 1
45 7538070 MACHINE SCREW 2
46 8121468300 SENSOR, INLET AIR TEMP (DCA250SSI). 1 ................REPLACES P/N 0603210240
47 C2224000513 CONTROL PANEL 1
48 C2224001504 CONTROL PANEL ......................................1 ................DCA250SSI
48 M5224000104 CONTROL PANEL ......................................1 ................DCA250SSIU
48-1 0228800190 RUBBER SEAL 2
48-2 0228800115 RUBBER SEAL 2
49 0605011211 PIN 2
50 0601807622 FREQUENCY METER, 45~65Hz 200V 1
51 0601806980 AC AMMETER, O~400A 0~800A 1
52 0601801040 CHANGE- OVER SWITCH, AMMETER 1
53 0601806887 AC VOLTMETER, O~600V 1
54 0601801041 CHANGE- OVER SWITCH, VOLTMETER 1
55 0601810072 PILOT LAMP 1
55A 0601810261 BULB 1
56 0601840073 RHEOSTAT (VR), 2W 1K OHM 1
57 0601840100 KNOB 1
58 ECU9988N220V ENGINE CONTROLLER, ECU-9988N 1
58A 0021004040 MACHINE SCREW 2
58B OEMAA8 SELF-LOCKING NUT ..................................2 ................REPLACES P/N 0207004000
59 0601830765 SWITCH ......................................................1 ................DCA250SSI
59 82608 SWITCH ......................................................1 ................DCA250SSIU
60 0601810171 PANEL LIGHT 1
61 OEMAA8 HEX NUT 2
61A 0027104020 MACHINE SCREW 2
62 0601830710 SWITCH, PANEL LIGHT 1
63 C9221100004 HEX HEAD BOLT 2
63A 0040008000 WASHER, LOCK 2
63B 0401450080 WASHER, FLAT 2
63C 0080200007 SNAP RING 2
64 0017108040 HEX HEAD BOLT 4
65 3871824004 STOPPER, CONTROL PANEL ...................1 ................DCA250SSI
65 M4213600104 STOPPER, CONTROL PANEL ...................1 ................DCA250SSIU
66 952404470 WASHER, FLAT 1
67 505015300 SNAP PIN 1
68 0601820892 OVER CURRENT RELAY 1
