TLG-12SPX — PARTS AND OPERATION MANUAL (STD) — REV. #4 (03/08/05) — PAGE 65
NO. PART NO. ITEM QTY. REMARKS
ENCLOSURE ASSY.
TLG-12SPX --- ENCLOSURE ASSY.
1 8525110012 BASE 1
8525910003 ACOUSTIC SHEET 1
2 8525110604 FLOOR PANEL 1
3 0017106016 HEX. HEAD BOLT 8
4 8525118003 PANEL 1
8525911004 ACOUSTIC SHEET 1
5 0017106016 HEX. HEAD BOLT 8
6 8525114003 DUCT 1
8525912004 ACOUSTIC SHEET 1
7 8525115003 BATTERY FRAME 1
8525913004 ACOUSTIC SHEET 1
8 0017106016 HEX. HEAD BOLT 8
9 8525181103 SPLASHER PANEL 1
8525980004 ACOUSTIC SHEET 1
10 8525181203 SPLASHER PANEL 1
8525980004 ACOUSTIC SHEET 1
11 0017106016 HEX. HEAD BOLT 12
12 8525120003 FRONT FRAME 1
8525920003 ACOUSTIC SHEET 1
13 0601850239 GROMMET ...................................... 2 ......... B142
14 0601850253 GROMMET ...................................... 2 ......... B362
15 8525125003 DUCT COVER 1
8525922003 ACOUSTIC SHEET 1
16 0017106016 HEX. HEAD BOLT 5
17 011008020 HEX. HEAD BOLT ............................ 2 ......... REPLACES 0017108020
18 8525121102 FRONT FRAME 1
8525921004 ACOUSTIC SHEET 1
19 011008020 HEX. HEAD BOLT ............................ 9 ......... REPLACES 0017108020
20 8522030003 FAN GUARD 1
21 0017106016 HEX. HEAD BOLT 4
22 8525132113 HANGER .......................................... 1 ......... S/N5107198 TO 5107225
8525132223 HANGER .......................................... 1 ......... S/N5107226~
23 8525132013 HANGER .......................................... 1 ......... S/N5107198 TO 5107225
8525132023 HANGER .......................................... 1 ......... S/N5107226~
24 0012312030 HEX. HEAD BOLT 6
THE PART NUMBER DEFAULT IS SCARLET COLOR.
INDICATE THE LETTERS BELOW TO INDICATE
DIFFERENT COLOR OF UNIT:
MQW-WHITE
THE SERIAL NUMBER MAY BE REQUIRED.
