General Inspection Prior to Operation
The TLG-12SPX generator has been thoroughly inspected
and accepted prior to shipment from the factory. However,
be sure to check for damaged parts or components, or loose
nuts and bolts, which could have occurred in transit.
Circuit Breaker
To protect the generator from an overload, a 3-pole, 65 amp,
circuit breaker is provided to protect the UNV output terminals
from overload. Make sure to switch circuit breaker to the
"OFF" position prior to starting the engine.
)
