page 10 — Tp24X TILe SaW • operaTIon and parTS manuaL — rev. #2 (04/12/12)
specificatiOns
Table 1. Saw Specifications
model TP24X
Blade Capacity 10 in. (254 mm)
Blade rpm 3200
arbor Size 5/8 in. (15.875 mm)
Blade guard Cast Aluminum
Blade Shaft Bearings Water-Cooled
Cutting Head Cast Aluminum, Adjustable
Conveyor Cart
Aluminum with roller bearings, injected
molded rubber pad, transportation lock
drive System V-belt
max. depth of Cut 3-1/2 in. (90 mm)
Straight Cut 24 in. (610 mm)
diagonal Cut 18 in. (457 mm) x 18 in. (457 mm) Size Tile
Water Tray ABS
Water pump 115V, 60 Hz — 100 GPH
Weight 103 lbs. (46.7 kg)
Table 2. electric motor Specifications
Horsepower 1-1/2
volts 115
amps 15
motor rpm 3450 RPM
Cycle 60
phase 1
Class E
