Mb25hd — housing assembly (continued) – Multiquip MB25HD User Manual
Page 25
MB25hd reBar BeNder • operaTioN aNd parTs MaNual — rev. #0 (04/05/10) — page 25
MB25Hd — HOusinG asseMBly (COntinued)
No.
parT No.
parT NaMe
QTY.
reMarKs
B72
H9XR0410M0
BOLT XR456
4
B73
M5T4328300
ANGLE SELECT KNOB
1
B74
MSRP054000
SPRING PIN SRP5540
1
B75
7540020
BOLT XF 5X15
2
B76
7810040
SPRING PIN SRP 4X16
2
B77
3503610
ANGLE SELECT GUIDE B
1
B78
M5HB082500
BOLT HB 8X25
1
B79
M5SCNH3002
FOOT SWITCH CONNECTOR F
1
B80
3302320
PANEL A
1
B81
M5HDLCP272
RUBBER CAP (ø27.2)
1
B82
M5T4269000
HANDLE
1
B83
C5HB0830M0
BOLT HB 8X30
2
B84
M5T42272N1
HANDLE BRACKET
1
B85
M5SRP10350
SPRING PIN SRP10X36 (STAINLESS)
1
B86
M5SRP05260
SPRING PIN SRP 5X25
1
B87
M5HB082000
BOLT HB 8X20
1
B88
7700020
NUT NM3
1
B89
M5T43284N1
ANGLE SELECT BAR
1
B90
M5T4330700
SPIRAL GEAR A
1
B91
M5WM160100
WASHER WM16
1
B92
M5T4328800
COIL SPRING
1
B93
7101040
BALL BEARING 6002Z
1
B94
M5T4459900
ROLLER SHAFT
1
B95
M5SB123500
BOLT SB 12X35
4
B96
M5XR0410M0
BOLT W/WASHER, LOCK XR4510
6
B97
M5T4332800
PANEL B
1
B98
M5XR0410M0
BOLT W/WASHER, LOCK XR4510
4
B99
C5HB0830M0
BOLT HB 8X30
2
B100 90003000
HANDLE SET
1
B101 M5T4332900
PANEL C
1
B102 C5HB0830M0
BOLT HB 8X30
2
B103 90003000
HANDLE SET
1
B104# 7538090
BOLT W/WASHER, LOCK XR 5X10
1
B105# 7538160
BOLT W/WASHER, LOCK XR 5X25
1
B106# 7538190
BOLT W/WASHER, LOCK XR 5X15
1
B107 M5KOKUSFM1
FOOT SWITCH ASSEMBLY
1
B108 M5SCH3002P
FOOT SWITCH CONNECTOR
1
B109# M5OPR10900
RECTIFIER
1
B110# 6200410
MAGNET SWITCH
1
B111# M5MGSWBOX0
MAGNET SWITCH BOX
1
B112 M5SK20ASSY
MAGNET SWITCH ASSEMBLY ............................ 1 ...........INCLUDES ITEMS W/#
