MB25hd reBar BeNder • operaTioN aNd parTs MaNual — rev. #0 (04/05/10) — page 17
No.
parT No.
parT NaMe
QTY.
reMarKs
A
M5M0115V00
MOTOR ASSY., 115V ............................................ 1 ...........INCLUDES ITEMS W/#
A1#
M5CBC65D00
CARBON BRUSH CAP
1
A2#
M5CBS65D00
CARBON BRUSH ................................................. 1 ...........INCLUDES ITEM A7 (SET)
A3#
6070020
CARBON BRUSH HOLDER
1
A4#
M5T2059400
MOTOR CASE
1
A5#
M5HB0520M0
BOLT HB 5X20
4
A6#
6070020
CARBON BRUSH HOLDER
1
A7#
M5CBS65D00
CARBON BRUSH ................................................. 1 ...........INCLUDES ITEM A2 (SET)
A8#
M5CBC65D00
CARBON BRUSH CAP
1
A9#
C5T4225600
HALF OPEN COVER
1
A10# H9XR0410M0
BOLT XR 4X6
2
A11# M5STR65D00
STATOR, 115V
1
A12# 6077110
TRIANGLE WASHER
2
A13# 6077070
FAN GUIDE
1
A14#% M5B608ZZ00
BALL BEARING 608ZZNC
1
A15#% M5T4248200
WASHER, ARMATURE
1
A16# M5AM115V00
ARMATURE, 115V ................................................ 1 ...........INCLUDES ITEMS W/%
A17#% M5B6201Z00
BALL BEARING 6201ZZNC
1
A18# M5XR051100
BOLT W/LOCK WASHER XR 5X110
4
A19
M5T4230400
MOTOR RING
1
A20
M5NM101M00
NUT NM10
4
A21
M5SW1001M0
WASHER SW10
4
A22
3300080
LINER (PILLOW BLOCK)
2
A23
M5UCF20500
PILLOW BLOCK UCF205
1
A24
M5SB1030M0
BOLT SB 10X35
4
A25
3600380
SHAFT WITH GEAR
1
A26
3701200
KEY FOR SHAFT WITH GEAR
1
A27
M5B6006Z00
BALL BEARING 6006Z
1
A28
C5HB0830M0
BOLT HB 8X30
4
A29
M5T2073300
MOTOR BASE
1
A30
H9B6080000
BALL BEARING 608
1
A31
C5T4217900
GEAR NO.2
1
A32
M5SNR20S00
STOP RING S20
1
A33
M5B6204Z00
BALL BEARING 6204Z
1
A34
M5T4329800
GEAR NO.3
1
A35
M5HB084500
BOLT HB 8X50
4
A36
C5SW0801M0
WASHER SW8
4
A37
M5T2073400
GEAR CASE
1
A38
M5K0404060
KEY FOR GEAR NO.3
1
A39
M5HB082500
BOLT HB 8X25
1
A40
C5B6202000
BALL BEARING 6202
1
MB25Hd — Case asseMBly
