MB25hd reBar BeNder • operaTioN aNd parTs MaNual — rev. #0 (04/05/10) — page 19
MB25Hd — Case asseMBly (COntinued)
No. parT No. parT NaMe QTY. reMarKs
A41 7410040 STOP RING S24 1
A42 M5B6205Z00 BALL BEARING 6205Z 1
A43 3503500 COLLAR NO.1 FOR GEAR NO.5 1
A44 3601890 GEAR NO.5 1
A45 M5K0707300 KEY FOR GEAR NO.5 1
A46 3602180 GEAR NO.6 1
A47 M5B6004000 BALL BEARING 6004Z 1
A48 M5SNR47H00 STOP RING H47 1
A49 M5B6005Z00 BALL BEARING 6005Z 2
A50 M5T4330000 GEAR NO.4 1
A51 M5T4329600 COLLAR NO.2 (CLUTCH) 1
A52 M5CLMMC500 MAGNET CLUTCH (MMC-5) 1
A53 M5SRP05260 SPRING PIN SRP5530 1
A54 7513000 BOLT HB 6X10 6
A55 M5T4336300 LINER B 1
A56 M5B6004000 BALL BEARING 6004Z 1
A57 M5T2073500 GEAR CASE COVER 1
A58 3300100 LINER S (GEAR CASE COVER) 2
A59 3300090 LINER L (GEAR CASE COVER) 2
