PAGE 12 — HPHA36C5H WALK-BEHIND TROWEL— OPERATION AND PARTS MANUAL — REV. #3 (07/06/10 )
HPHA36C5H TROWEL— OPERATION AND SAFETY DECALS
Figure 1. HPHA36C5H Trowel Decals
P/N 20526
Q U
I C K
P I T C H
P/N 20815
P /N 20814
FINISH J
COMBO
PRELOAD TRIM INDICATOR
FINISH B
COMBO
P/N 1735
Symbol indicates that it is mandatory to wear
safety glasses, safety helmet and ear protection.
Symbol indicates that it is mandatory to
wear safety shoes, with extra protection
(steel toed).
This is the symbol for belt drive.
This is the symbol for gear drive.
Radiating heat symbol. Symbol indicates equipment
is hot.
Symbol for examining or checking of the machine.
Mostly used for maintenance. Check lubrication
oil in gearbox.
Symbol indicates that it is mandatory to wear
gloves.
P/N 11247
(Part of decal kit 12620)
P/N 11247
(Part of decal kit 12620)
P/N 11247
(Part of decal kit 12620)
P/N 11246
(Part of decal kit 12620)
P/N 11246
(Part of decal kit 12620)
P/N 11246
(Part of decal kit 12620)
P/N 11246
(Part of decal kit 12620)
CONTACT MULTIQUIP
SERVICE DEPT.
NAMEPLATE
DO NOT OPERATE HANDLE UNTIL IT IS
SECURELY FASTENED TO POWER TROWEL
& INSTRUCTIONS HAVE BEEN READ
INJURY COULD RESULT IF FINISHER IS LIFTED
WITHOUT PITCH HANDLE FIRMLY ENGAGE
WARNING!
WARNING!
DO NOT LIFT MACHINERY BY GUARD
RING. MAY CAUSE DAMAGE TO
GUARD RING SHOCK MOUNTS
USE LIFT HANDLES ONLY
CAUTION
P/N 1261
P/N 20527
PO
WER TROW
EL
P/N 1736
P/N 20816
P /N 20820
OPERATION AND SAFETY DECALS
The HPHA36C5H walk-behind trowel is equipped with a number of operation, safety and maintenance decals. Should any of these
decals become unreadable, replacements can be obtained from your dealer.
