HHXg5 RIDe-ON TROWeL • OpeRaTION maNuaL — Rev. #1 (10/25/10) — page 15
SpecificatiOnS (enGine)
Table 2. HHXg5 engine Specifications
model vanguard Dm950g
Type Gasoline
Cylinders 3
Displacement 58.1 cu.in. (952 cc)
Power (Maximum Output) 31 HP (23.1 kW) @3600 rpm
Bore and Stroke 2.83 in. x 3.07 (72 mm x 78 mm)
Maximum Torque (Intermittent) 70.0 Nm @ 2200 rpm
Compression Ratio 8.7 : 1
Cooling System Fully jacketed water-cooled
Engine Oil Capacity
3.2 qt. (3 liters)
3.5 qt. (3.3 liters) w/ oil filter
replacement
Lubricating System Pressure feed with spin-on filter
Fuel Tank 9 gal. (34 liters)
Fuel Delivery System Carbureted
Helical Gearbox Gear
Compound Capacity
144 oz. (4.26 liters)
ISO 22O AGMA GR 5EP
Fuel
Gasoline - minimum of 87 octane
rating
Starting System Electric Starter
Dry Weight 143.3 lbs. (65 Kg)
Dimensions (L x W x H)
17.4 in. x 17.1 in. x 19.7 in
(441.8 mm x 443.2 mm x 501.4
mm).
