MS120 HYDRAULIC MIXER • OPERATION AND PARTS MANUAL — REV. #0 (07/10/08) — PAGE 75
NO. PART NO. PART NAME QTY. REMARKS
1 30500ZF6W02 COIL ASSEMBLY, IGNITION ....................... 1 ......... REPLACES 305007E2023
1
◊◊◊◊◊
30500ZF6W02 COIL ASSEMBLY, IGNITION ....................... 1 ......... S/N 1411816 AND BELOW
1
◊◊◊◊◊
30500ZF6W03 COIL ASSEMBLY, IGNITION ....................... 1 ......... S/N 1411817 AND ABOVE
2 30700ZE1013 CAP ASSEMBLY, NOISE SUPPRESSOR 1
5 31512ZE2000 GROMMET, WIRE 1
8 36101ZE2701 WIRE, STOP SWITCH 430MM 1
12 90015883000 BOLT, FLANGE 6X28 2
13
◊◊◊◊◊
90684ZA0601 CLIP, HARNESS 1
HONDA GX390K1QA2/GX390U1QA2 — IGNITION COIL ASSY.
GX390K1QA2: Model MS120 December 2006 And Below
◊◊◊◊◊ GX340U1QA2: Model MS120 January 2007 And Above
