MS120 HYDRAULIC MIXER • OPERATION AND PARTS MANUAL — REV. #0 (07/10/08) — PAGE 45
NO PART NO PART NAME QTY. REMARKS
1# EM203449 MOVEABLE GRATE 1
2# 7170 PIN, HITCH CLIP 5/32" 3-5/16" 2
3# 6109170 WASHER, FLAT 1/2" 3
4# 13276Y BAR, GRATE 1
5# EM969013 NUT, NYLOC 3/8" 4
6# EM621 WASHER, FLAT 1/2" SPECIAL 4
7# 491008 CAP, GREASE FITTING 4
8# EM916019 GREASE FITTING 4
9# EM963105 SCREW, HHCS 1/2" NC X 2" G5 ................... 4....... REPLACES EM492396
10# 13260Y FRONT DUMP SUPPORT BRACKET 1
11# 3249Y CAP, DUST 1
12# EM963610 HHCS 3/8" NC X 1-1/4" G8 4
13# EM924015 PIN, COTTER 3/16" X 1 2
14# 3291 BEARING HOUSING FRONT 1
15# 516457 BEARING HOUSING, REAR 1
16# 13259Y REAR DUMP SUPPORT BRACKET 1
17 509000 COTTER PIN 3/16" X 2" 1
18 13228 PIN, DUMP CYLINDER 1
19 3327 CYLINDER, DUMP 1
20 511495 LOCK NUT 1" NC 1
21 13286Y SPACER, LOWER HYDRAULIC CYLINDER 1
22 511526 SCREW HHCS 1" NC X 8 1
23 3047 SPACER, 2" X 1-1/8 X 1/4" L 2
24# EM963692 HHCS 1/2"-13 X 1-1/2" 7
25# 492584 NUT, LOCK 1/2" 11
26# 516535Y STEEL DRUM, HYDRAULIC 1
27 511173 DRUM AND SHAFT ASSY. HYDRAULIC ....... 1....... INCLUDES ITEMS W/#
STEEL DRUM ASSY. (HYDRAULIC)
