MS120 HYDRAULIC MIXER • OPERATION AND PARTS MANUAL — REV. #0 (07/10/08) — PAGE 41
NO. PART NO. PART NAME QTY. REMARKS
2 492584 NUT, LOCK 1/2" 8
3 EM200295A PADDLE ARM, CENTER TOW END 1
5 EM200292 INSERT, PADDLE ARM 8
6 EM200293A PADDLE ARM, TOW END 1
7 6109170 WASHER, FLAT 1/2" 8
8 EM200297 U-BOLT, END PADDLES 4
9 EM200294A PADDLE ARM, CENTER ENGINE END 1
10 * 492366 SCREW, HHC 5/16-18 X 1-1/2 G5 14
11 * EM923023 WASHER, FLAT 5/16" STEEL 28
12 * EM200212 WIPER, SIDE (RUBBER) 4
13 * EM203432 SCRAPPER, SIDE 4
14 * 2105164 NUT, HEX 5/16" 14
15 * EM923343 WASHER, LOCK 5/16" 14
16 EM200296A PADDLE ARM, ENGINE END 1
17 * EM203433 SCRAPPER, END 2
18 * EM200213 BLADE, RUBBER (END) 2
19 EM200863 KIT, RUBBER BLADES, SCRAPERS & HARDWARE .... 1............ INCLUDES ITEMS W/ *
PADDLE BLADES ASSY.
