MS120 HYDRAULIC MIXER • OPERATION AND PARTS MANUAL — REV. #0 (07/10/08) — PAGE 43
NO
PART NO
PART NAME
QTY.
REMARKS
1#
EM203449
GRATE, MOVABLE
1
2#
7170
5/32" 3-5/16"
2
3#
6109170
WASHER, FLAT 1/2"
3
4#
13276Y
BAR, GRATE LATCH
1
5#
EM969013
NUT, NYLOC 3/8"
8
6#
EM621
WASHER, FLAT 1/2" SPECIAL
4
7#
491008
CAP, GREASE FITTING
4
8#
EM916019
GREASE FITTING
4
9#
EM963105
SCREW, HHCS 1/2" NC X 2" G5 ............... 4........... REPLACES EM492396
10#
13260Y
FRONT DUMP SUPPORT BRACKET
1
11#
3249Y
CAP, DUST
1
12#
EM963610
HHCS 3/8" NC X 1-1/4" G8
8
13#
EM924015
PIN, COTTER 3/16" X 1
2
14#
3291
BEARING HOUSING FRONT
1
15#
516457
BEARING HOUSING, REAR
1
16#
13259Y
REAR DUMP SUPPORT BRACKET
1
17#
EM963692
HHCS 1/2"-13 X 1-1/2"
1
18#
492584
NUT, LOCK 1/2"
7
19#
512245Y
STEEL DRUM, MANUAL
1
20
EM201537Y
MANUAL DUMP HANDLE
1
21
512180
DRUM AND SHAFT ASSY. MANUAL ......... 1........... INCLUDES ITEMS W/#
STEEL DRUM ASSY. (MANUAL)
