MS120 HYDRAULIC MIXER • OPERATION AND PARTS MANUAL — REV. #0 (07/10/08) — PAGE 61
NO. PART NO. PART NAME QTY. REMARKS
1 13010ZF6003 RING SET, PISTON (STD.) 1
1 13010ZF6005 RING SET, PISTON (STD.) 1
1 13011ZF6003 RING SET, PISTON (OS 0.25), OPT. 1
1 13011ZF6005 RING SET, PISTON (OS 0.25), OPT. 1
1 13012ZF6003 RING SET, PISTON (OS 0.50), OPT. 1
1 13012ZF6005 RING SET, PISTON (OS 0.50), OPT. 1
1 13012ZF6005 RING SET, PISTON (OS 0.50), OPT. 1
1 13013ZF6003 RING SET, PISTON (0.75) NIP.,OPT. 1
1 13013ZF6005 RING SET, PISTON (0.75) NIP.,OPT. 1
2 13101ZF6W00 PISTON (STANDARD) 1
2 13102ZF6W00 PISTON (OS 0.25), OPTIONAL 1
2 13103ZF6W00 PISTON (OS 0.50), OPTIONAL 1
2 13104ZF6W00 PISTON (0.75), OPTIONAL 1
3 13111ZF6W00 PIN, PISTON 1
4 13200ZE3010 ROD ASSY., CONNECTING (STD.) ......... 1 ....... INCLUDES ITEMS W/ *
............................................................................ SN 3177434 AND BELOW
4 13200ZE3020 ROD ASSY., CONNECTING (STD.) ......... 1 ....... INCLUDES ITEMS W/ *
............................................................................ SN 3177435 AND ABOVE
4 13200ZE3315 ROD ASSY., CONNECTING (US 0.25) ..... 1 ....... INCLUDES ITEMS W/ *
4
◊◊◊◊◊ 13200ZE3020
ROD ASSY., CONNECTING (STD.) ......... 1 ....... INCLUDES ITEMS W/ *
4
◊◊◊◊◊ 13200ZE3315
ROD ASSY., CONNECTING (US 0.25) ..... 1 ....... INCLUDES ITEMS W/ *
5 * 90001ZE8000 BOLT, CONNECTING ROD 2
6 90601ZE3000 CLIP, PISTON PIN 20MM 2
HONDA GX390K1QA2/GX390U1QA2 — PISTON ASSY.
GX390K1QA2: Model MS120 December 2006 And Below
◊◊◊◊◊ GX340U1QA2: Model MS120 January 2007 And Above
