MQ62TDD TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #0 (07/30/09) — PAGE 61
TRASH PUMP ASSY. (CONTINUED)
NO. PART NO. PART NAME QTY. REMARKS
48 0105090815 BOLT ( MECHANICAL SEAL HOUSING) 4
49 0451290080 WASHER, LOCK 4
50 0105091225 BOLT, IMPELLER 1
51 0451250120 WASHER, LOCK 1
52 011008040 BOLT, SHAFT 6
53 030208200 WASHER,LOCK 1
54 0105051645 BOLT, CASING 14
55 030216400 WASHER, LOCK 14
56 012010030 BOLT, CASING COVER 6
57 030210250 WASHER, LOCK 6
58 0105052030 BOLT ( OIL CAP ) 3
59 4607287110 OIL CAP WASHER 3
60 012010030 BOLT ( SUCTION CASE ) 2
61 030212300 WASHER, LOCK 2
62 014210020 CAP SCREW ( WEAR PLATE )........................... 3.............REPLACES 0131191020
63 0151161035 STUDIO BOLT ( VOLUTE CASING ) 2
64 0151151240 STUD BOLT ( DRAIN COVER B ) 2
65 0458220100 SEAL WASHER 2
66 030210250 WASHER, LOCK 2
67 0204450100 NUT VOLUTE CASING 2
68 0742062150 STRAINER 1
70 KITMQ62 KIT, SEAL AND O-RINGS 1 INCLUDES ITEMS W/%
