MQ62TDD TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #0 (07/30/09) — PAGE 103
NO. PART NO. PART NAME QTY. REMARKS
1 CONTROL BOX ............................. 1 ..........INCLUDES ITEMS W/% — SEE NOTE BELOW
2% 01180384 SIGNAL LIGHT 1
3% 01180382 SIGNAL LIGHT 1
4% 01180383 SIGNAL LIGHT 1
5% 01182528 PREHEAT STARTER SWITCH ...... 1 ..........INCLUDE ITEMS W/#
6% 04179738 CABLE HARNESS 1
7% 04179735 CABLE HARNESS 1
8% 01112802 HEXAGON NUT 1
9% 01112195 HEXAGON BOLT 1
10% 01140498 WASHER, FLAT 1
11% 01117860 TOOTH LOCK WASHER 1
12% 01180017 CLAMPING BAND 1
13%# 01182529 IGNITION KEY 1
CONTROL BOX ASSY. (OLD STYLE)
OLD STYLE CONTROL BOX NO LONGER AVAILABLE.
WHEN REPLACING CONTROL BOX, USE P/N 34708.
SEE NEW STYLE CONTOL BOX ASSEMBLY NEXT
PAGE.
