MQ62TDD TRASH PUMP • OPERATION AND PARTS MANUAL — REV. #0 (07/30/09) — PAGE 19
PUMP COMPONENTS
Figure 4 shows the location of the components and basic
components for the MQ62TDD trash pump, The function
of each component or control is described below:
1. Lifting Bail – When lifting of the trash pump by crane
is required, use this lifting bail. Note: this lifting bail is
balanced for a fully configured trash pump; removal of
any trash pump components will un-balance the lifting
bail.
2. Pump Discharge Port – Discharges water and debris
from the pump.
3. Muffler/Guard – DO NOT touch the muffler when
engine is running. The muffler can become extremely
hot, causing severe burns. NEVER run the pump with
the muffler guard removed.
4. Oil Filler – Fill as recommended in the maintenance
section of this manual.
5. Engine (Diesel) – This pump uses a Deutz F2L2011/
D2011L02 air-cooled, 4-stroke diesel engine. See the
Deutz Operation manual supplied with the trash pump
for additional engine information.
6. Control Box Panel – Monitors engine functions and
will shut down the engine for low oil pressure, high
coolant temperature, alternator charge and V-belt
failure.
7. Battery – +12 VDC battery compartment.
8. Tow End Jack Stand – When connecting the pump to
a ball type towing hitch, use this jack stand to raise
and lower the pump.
9. Fuel Filler Port – When the adding of fuel is required,
remove fuel cap and add fuel through this port. Re-
fuel using only recommended types of diesel fuels (see
Deutz Operation Manual). DO NOT top off fuel, wipe
up any spilled fuel immediately.
10. Tow Hitch Coupler – Requires a 2-inch ball hitch.
11. Safety Chain – ALWAYS attach safety chain to the
towing vehicle. NEVER! tow the trash pump with the
safety chain unattached.
12. Documentation Box – Contains documentation for the
pump and engine.
13. Fuel Cell – This pump can be configured to operate
with either a 16, 23 or 41 gallon fuel cell.
14. Tie-Downs – When the pump is placed on a flatbed
truck for transport, use these tie-down points (4) to
secure the trailer frame to the flatbed.
15. Fuel Cell Drain Plug – Located underneath the fuel
cell, remove this drain plug to drain the fuel tank.
16. Engine Throttle Lever – Controls the speed of the
engine. For load conditions (pumping water) ALWAYS
run the engine at
full speed.
17. Dipstick – Read this gauge to determine the oil level
in the engine crankcase. Fill with only recommended
type oil as referenced in the maintenance section of
this manual.
18. Fuel Filter – Replace or clean the fuel filter as specified
in the maintenance section of this manual.
19. Chock Blocks – Place these blocks (not included as
part of the trash pump package) under each trailer
wheel to prevent rolling.
20. Fuel Gauge – Read this gauge to determin if the fuel
level is low is low. If fuel level is low, replenish with only
recommended type diesel fuel.
21. Clean-Out Cover – Remove this cover to clean and
remove foreign debris from the trash pump.
22. Accessories – Hoses, strainers and clamps are the
required accessory components for normal operation
of this trash pump.
Contact your nearest Multiquip
dealer for information on the components.
23. Trailer Lights – Before towing trash pump, make sure
that both trailer lights are functioning correctly. NEVER
tow the trash pump if these lights are not working.
24. Pump Intake Port – Intakes water and debris from
the source.
25. Fill Cap – Remove this cap to prime the pump with
water.
