page 12 — mvh406dsz/dsCpas pLaTe COmpaCTOR • OpeRaTiOn and paRTs manuaL — Rev. #7 (02/28/14)

DIMENSIONS

Figure 1. MVH406DSZ/DSCPAS Reversible Plate

Compactor Dimensions

MVH-406

E

B

D

A

C

Table 3. dimensions

A

55.12 in. (140 mm.)

B

19.69 in. (50 cm.)

C

35.3 in. (90 cm.)

D

63.39 in. (161 cm.)

E

41.34 in. (105 cm.)
