mvh406dsz/dsCpas pLaTe COmpaCTOR • OpeRaTiOn and paRTs manuaL — Rev. #7 (02/28/14) — page 11
SpECIfICATIONS
Table 1. mvh406dsz/dsCpas Reversible
plate Compactor specifications
Centrifugal Force 12,346 lbs. (5,600 kg)
Vibration Frequency 4,600 vpm (77 Hz)
Traveling Speed 0 to 75 ft/min (0 to 23 m/min)
Plate Size (L x W) 35.43 x 19.69 in (90 x 50 cm)
External Plate Size (L x W) 35.43 x 25.59 in (90 x 65 cm)
Max. Area of Compaction (no extensions) 7,510 sq. ft. (2,289 sq. meters)
Length (handle in working position) 63.39 in (1610 mm)
Height (handle in working position) 41.34 in (1050 mm )
Length (handle in vertical position) 37.6 in (955 mm )
Height (handle in vertical position) 55.12 in (1400 mm )
Operating Weight (without extension plates) 903.88 lbs. (410 kg)
Operating Weight (with extension plates) 948 lbs. (430 kg)
Lubricating Oil in Vibration Case 20.28 fl. oz. (600 cc)
Table 2. engine specifications
Engine Make FUJI HEAVY INDUSTRIES
Engine Model Robin D1B40T92040
Engine Type 10 HP, Air-cooled 4-cycle Diesel Engine
Cylinder Bore X Stroke 3.5 x 3.45 in (88 x 76 mm)
Displacement 15.6 fl oz (462 cm3)
Maximum Ouput 9.6 HP @3,200 RPM (7.2 kw @3,200 RPM)
Fuel Tank Capacity 5.2 quarts (5.0 liters)
Oil Capacity 1.6 quarts (1.55 liters)
Starting Method D/DS Recoil/Electric
Dry Net Weight Recoil/Electric 118.3 lbs. (53.3 kg)
Dimensions (L x W x H) 12.40 x 15.51 x 18.89 in (315 x 394 x 480 mm)
