page 24 — mvh306ds2/dsCpas pLaTe COmpaCTOR • OpeRaTiOn and paRTs manuaL — Rev. #7 (02/04/14)
inspection and maintenance service Tables.
To make sure your plate compactor is always in good
working condition before using, carry out the maintenance
inspection in accordance with Table 5 thru Table 7.
CauTiOn
Inspection and other services should always be carried
out on hard and level ground with the engine shutdown.
Table 5. mvh-306ds2/dsCpas machine inspection
item hours of Operation
Loose or Missing Screws Every 8 hours (every day)
Damaged Parts Every 8 hours (every day)
Function of Controlling
System Part
Every 8 hours (every day)
Hydraulic System Leak Every 100 hours
Vibrator Oil Check Every Every 100 hours
Vibrator Oil Replacement Every 300 hours
Hydraulic Oil Check Every Every 100 hours
Hydraulic Oil Replacement
First after 200 hours, then every
1,000 hours
V-belt (clutch) Check Every 200 hours
Battery Check Every 100 hours
CauTiOn
These inspection intervals are for operation under
normal conditions. Adjust your inspection intervals
based on the number hours plate compactor is in use,
and particular working conditions.
NOTICE
Fuel piping and connections should be replaced every
2 years.
MAINTENANCE
Table 6. mvh-306ds2/dsCpas engine Check
item hours of Operation
Oil or Fuel Leak Every 8 hours (every day)
Tightness of Fastening
Threads
Every 8 hours (every day)
Engine Oil Check and Re-
plenishment
Every 8 hours (every day) (Re-
plenish to specified maximum
level)
Engine Oil Replacement
After first 25 hours then every 50
to 100 hours
Air Filter Cleaning Every 100 hours
See separate engine manual for details on engine check.
daily service
„ Check for leakage of fuel or oil.
„ Check for loose screws including tightness. See Table 7
below (tightening torque ), for retightening:
Table 7. Tightening Torque
(in. kg/cm) diameter
Material 6mm 8mm 10mm 12mm 14mm 16mm 18mm 20mm
4T 70 150 300 500 750 1,100 1,400 2,000
6-8T 100 250 500 800 1,300 2,000 2,700 3,800
11T 150 400 800 1,200 2,000 2,900 4,200 5,600
* 100
300~
350 650~
700
* (In case counter-part is of aluminum)
(Threads in use with this machine are all right handed)
Material and quality of material is marked on each bolt, and screw.
„ Remove soil and clean the bottom of compaction plate.
„ Check hand pump, piping and hose for any leakage. A
loosened hydraulic hose can be a cause for leakage.
Check hydraulic hose connections with wrench applied
for tightness.
„ Check engine oil.
