mvh306ds2/dsCpas pLaTe COmpaCTOR • OpeRaTiOn and paRTs manuaL — Rev. #7 (02/04/14) — page 11
SpECIfICATIONS
Table 1. mvh306ds2/dsCpas Reversible
plate Compactor specifications
Centrifugal Force
10,116 lbs. (4,588 kg)
vibration Frequency
3,600 vpm (60 Hz)
Traveling speed
0 to 75 ft/min (0 to 23 m/min)
plate size (L x W)
18 x 34 in (45.72 x 86.36 cm)
external plate size (L x W)
24 x 34 in (60.96 x 86.36 cm)
max. area of Compaction (no extensions)
6,750 sq. ft. (2,057 sq. meters)
Overall Length
62 in (1,575 mm)
Overall Width
18.0 in (457 mm )
Overall height (with handle)
55 in (1,397 mm )
Overall height (without handle)
34 in (864 mm )
Operating Weight
725 lbs. (329 kg.)
Operating Weight (extension plates)
824 lbs. (374 kg.)
Lubricating Oil in vibration Case
20.28 fl. oz. (600 cc)
Table 2. engine specifications
engine make
YANMAR
engine model
L70V6GJ1R1AAS5
Engine Type
Air-cooled 4-cycle Diesel Engine
Cylinder Bore X stroke
3.07 x 2.51 in (78 x 64 mm)
displacement
10.34 fl oz (306 cm3)
maximum Ouput
6.5 HP @3,600 RPM
Fuel Tank Capacity
3.5 quarts (3.31 liters)
Oil Capacity
1.16 quarts (1.10 liters)
starting method d/ds
Recoil/Electric
dry net Weight Recoil/electric
72.75 lbs. (33 kg)/83.77 lbs. (38 kg)
dimensions (L x W x h)
15.11 x 16.57 x 17.71 in (384 x 421 x 450 mm)
