mvh306ds2/dsCpas pLaTe COmpaCTOR • OpeRaTiOn and paRTs manuaL — Rev. #7 (02/04/14) — page 19
3. Insert the ignition key into the ignition switch and turn
it to the Run position (Figure 15). The buzzer should
sound at this time.
4. Turn the ignition key further to the right to the START
position to start the engine. Buzzer stops sounding and
the engine starts.
5. If the engine fails to start, dO nOT continue to rotate
the ignition key for more than 5 seconds. Return the
key to the Run position and wait 10 seconds before
starting again
Figure 15. Starter Switch (Option)
;
6. After starting the engine, continue to warm up the
engine for about 3 to 10 seconds especially in cold
weather.
7. If the buzzer does not stop sounding after the engine
has started, shutdown engine immediately and check
engine oil level. The buzzer functions as a engine oil
level alarm warning device.
NOTICE
When starting a unit with an electric strart capability, a
decompressor is not normally required. However, when
ambient temperature or battery charger level is low, use
of a decompressor will help make the start-up easier.
STOP
RUN
START
CauTiOn
While the engine is running, never try to turn the ignition
key to the START position.
OpERATION
Recoil Start
1. Place the fuel cock in the Open position (Figure 13).
2. Move the throttle lever to the START position
(Figure 14).
3. Grasp the starter grip (Figure 16) and slowly pull it
out. The resistance becomes the hardest at a certain
position, corresponding to the compression point. Pull
the starter grip briskly and smoothly for starting.
Figure 16. Engine Start Handle
4. Push down decompression lever (Figure 17) and
release.
Figure 17. Decompression Lever
5. If the engine does not start, repeat steps 1 thru 4
