MVC-82VH/VHW • OPERATION AND PARTS MANUAL — REV. #1 (04/25/08) — PAGE 59
HONDA GX160U1SM12 ENGINE — FUEL TANK ASSY.
NO. PART NO. PART NAME QTY. REMARKS
3 16854ZH8000 RUBBER, SUPPORTER (107MM) 1
7 16955ZE1000 JOINT, FUEL TANK 1
11 17510ZE1020ZF TANK, FUEL (BLACK) 1
12 17620Z4H000 CAP, FUEL FILLER ......................... 1 .......... INCLUDES ITEMS W/ *
13 * 17631Z0T812 GASKET, FUEL FILLER CAP 1
14 17672ZE2W01 FILTER, FUEL 1
17 90004ZH7003 BOLT, FLANGE (6 X 29) 1
18 90404680000 WASHER (6.5 X 25 X 1.5) 2
20 91319ME5003 O-RING (5.5 X 1.4) 2
21 91353671004 O-RING (14 MM) 1
24 9405006000 NUT, FLANGE (6MM) 2
27 950014514040 FUEL TUBE (4.5 X 140) 1
27 950014500160M BULK HOSE, FUEL (4.5 X 1M) 1
28 9500202080 CLIP, TUBE 2
