MVC-82VH/VHW • OPERATION AND PARTS MANUAL — REV. #1 (04/25/08) — PAGE 35
WATER TANK ASSY. (MVC82VHW ONLY)
NO. PART NO. PART NAME QTY. REMARKS
91 418118581 GUARD HOOK 1
92 002211025 BOLT 10X25 H, SW 3
101 418910080 WATER TANK W/CAP (ORANGE) ......... 1 .......... INCLUDES ITEMS W/ #
102# 954300342 CAP, WATER TANK (NBR) 1
103# 001241030 BOLT 10X30 U 1
104# 033910010 WASHER 10.5X21X2 SUS 2
105# 022910180 NYLON NUT M10 (SUS) 1
106 954403241 COCK PT1/4, BH-1211(AL) 1
107 959403790 NUT PS-1/4 1
108 418458320 PACKING 11.5X19.5X2 1
109 418345150 PIPE HOLDER 1
110 418345160 SPRINKLING PIPE 1
111 001740825 FLANGE BOLT 8X25 (SUS) 1
112 033910110 WASHER, FLAT M8 (SUS) 2
113 020308064 NUT M8 (SUS) 1
114 418459330 RUBBER CAP 1
115 416453780 PACKING 8X19X2T 1
116 418457890 RUBBER (SPRINKLINK) 2
