MVC-82VH/VHW • OPERATION AND PARTS MANUAL — REV. #1 (04/25/08) — PAGE 57
HONDA GX160U1SM12 ENGINE — MUFFLER ASSY.
NO. PART NO. PART NAME QTY. REMARKS
2 18310ZH8810 MUFFLER 1
4 18320ZF1H01 PROTECTOR, MUFFLER 1
5 18325ZE1010 PROTECTOR, LOWER 1
6 18340ZE1010 DEFLECTOR CP 1
7 18355ZE1000 ARRESTER, SPARK 1
9 18381ZH8800 GASKET, MUFFLER 1
15 18522ZE1000 GUIDE, MUFFLER 1
16 90002ZG0003 SCREW, TAPPING (4 X 8) 2
17 94001080000S NUT, HEX (8MM) 2
19 90050ZE1000 SCREW, TAPPING (5 X 8) 4
22 90055ZE1000 SCREW, TAPPING (4 X 6) 1
23 90055ZE1000 SCREW, TAPPING (4 X 6) 4
