MVC-82VH/VHW • OPERATION AND PARTS MANUAL — REV. #1 (04/25/08) — PAGE 31
BODY ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 419119550 VIB. PLATE 570X450 1
3 939010254 SHOCK ABSORBER D45H41 4
4 959404350 EARTH WIRE 1
5 020310080 NUT M10 8
6 030210250 WASHER, LOCK M10 8
7 031110160 WASHER, FLAT M10 4
11 912216004 ENGINE ASSY, GX160U1SM12 1
13 413436870 ENGINE NUT, REAR 1
14-1 001220840 BOLT 8X40 T 2
14-2 030208200 WASHER, LOCK M8 2
14-3 031108160 WASHER, FLAT M8 2
16 031108160 WASHER, FLAT M8 1
17 022710809 NYLON NUT M8 1
21 952400130 WASHER 9304 1
23 070100312 VBELT RPF3310 1
25 418216470 BELT COVER 1
26-1 001221035 BOLT 10X35 T 1
26-2 030210250 WASHER, LOCK M10 1
26-3 031110160 WASHER, FLAT M10 1
27 418216480 BELT COVER (IN) 1
28-1 001221053 BOLT 10X65 T 1
28-2 030210250 WASHER, LOCK M10 1
28-3 031110160 WASHER, FLAT M10 1
29 418343420 COVER SEAL (E/G) 1
31 020308060 NUT M8 4
32 030208200 WASHER, LOCK M8 4
33 031108160 WASHER, FLAT M8 2
36 419217800 BASE 1
37 418457750 BOLT, ENGINE 1
38 408421270 CLUTCH SPACER 20.2X25X9.4 1
39 413332920 CLUTCH ASSY S20A1-124 1
40 0053005201 KEY 1
41-1 001220820 BOLT 8X20 T 1
41-2 030208200 WASHER, LOCK M8 1
42 939010290 RUBBER, HANDLE 2
45 404433430 RUBBER 20X32X28.5/52H 2
46 952403450 WASHER 11X35X4.5 2
47-1 001221020 BOLT 10X20 T 2
47-2 030210250 WASHER, LOCK M10 2
60 419910010 VAS HANDLE ASSY .............................. 1 .......... INCLUDES ITEMS W/ #
61# 419219560 VAS HANDLE BODY 1
62# 419217810 GRIP, VAS HANDLE 1
63# 416459320 HANDLE NUT, VAS HANDLE 2
64# 416459340 RUBBER, VAS HANDLE 2
65# 009120407 SUNK HEAD BOLT 10X20 T 2
