MVC-82VH/VHW • OPERATION AND PARTS MANUAL — REV. #1 (04/25/08) — PAGE 37
HONDA GX160U1SM12 ENGINE — CYLINDER HEAD ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1% 12204ZE1306 GUIDE, IN. VALVE (OS), OPTIONAL 1
2% 12205ZE1315 GUIDE, EX. VALVE (OS), OPTIONAL ... 1 .......... INCLUDES ITEMS W/ #
3 12210ZH8405 HEAD COMP., CYLINDER ..................... 1 .......... INCLUDES ITEMS W/ %
4%# 12216ZE5300 CLIP, VALVE GUIDE 1
5 12251ZH1800 GASKET, CYLINDER HEAD 1
6 12310ZE1020 COVER, HEAD 1
7 12391ZE1000 GASKET, CYLINDER HEAD COVER 1
8 15721ZH8000 TUBE, BREATHER 1
9 90013883000 BOLT, FLANGE (6 X 12) 4
10 90043ZE1020 BOLT, STUD (6 X 112) 2
11 90047ZE1000 BOLT, STUD (8 X 32) 2
12 9430110160 PIN A, DOWELL (10 X 16) 2
14 957230806000 BOLT, FLANGE (8 X 55) 4
15 9807956846 SPARK PLUG BPR6ES (NGK) 1
