MRH800DS2 VIBRATORY ROLLER • OPERATION AND PARTS MANUAL — REV. #1 (04/12/11) — PAGE 19
COMPONENTS
HANDLE BAR/LEVER COMPONENTS
Figure 3 illustrates the location of the major lever
components on the handle bar of the machine. Each
component is described below:
1. Travel Lever — Controls the direction of travel of the
machine (forward and reverse).
2. Horn Button — When pressed, gives a warning sound
of the machine approaching.
3. Vibration Lever — Turns vibration on and off.
4. Throttle Lever — Controls the start up of the machine.
5. Dead-Man Device — When pressed or hit while
traveling in reverse, causes the travel lever to return
to neutral position to stop the machine.
6. Light ON/OFF Switch — Turns headlight on and off.
7. Starter Switch — Engine starts when key is turned
to the RUN position.
