16. Additional Set Ups
16. ADDITIONAL SET UPS
Overview
• Entering the Installation menu
• Image transition when switching between sources
• On Screen Display
• Internal Generated Testpatterns
• Auto Shutdown when no Input Signal
• Quick Access Keys
Summary of the additional set ups.
The additional set ups can be find as items of the Installation menu. The items are:
• The way of source switching.
• Place and color of the OSD on the screen.
• Available internal patterns.
• Shutdown yes or not and adjustable in time in case of no input signal.
• Overview of quick access keys.
16.1 Entering the Installation menu
How to enter the Installation menu
1. From the Adjustment mode menu, select item INSTALLATION. (menu 16-1)
The Installation menu appears on-screen and in the graphical display. (menu 16-2)
2. Respectively select the items after INPUT SLOTS and proceed to the set up (see below).
Note: Item CONFIGURATION is not active and as result not selectable.
ADJUSTMENT MODE
Select a path from below :
RANDOM ACCESS
INSTALLATION
SERVICE
Select with ↑ or ↓
then
to return
0HQX
INSTALLATION
INPUT SLOTS
SOURCE SWITCHING
CONFIGURATION
OSD
INTERNAL PATTERNS
NO SIGNAL
QUICK ACCESS KEYS
Select with ↑ or ↓
then
to return
0HQX
R5976519 ACSAR 12122002 91
