15. Image Alignment
15. IMAGE ALIGNMENT
Overview
• Entering the Random Access Mode menu
• Image Settings
• Picture in Picture (PIP)
• Framing the Image (Blanking)
• Adjusting the Image Aspect Ratio
• Image Side Keystone
• Vertical and Horizontal Image Shift
• Vertical and Horizontal Image Size
About set ups for the image
Set ups for the image are grouped in the Random Access Mode menu. The different main items are:
• IMAGE SETTINGS: contains the analog controls e.g. Contrast, Brightness, Tint.......
• PICTURE TUNING: contains decoder settings and Input Balance adjustment.
• GEOMETRY: contains the adjustments for image Size, Shift, Keystone, Aspect Ratio and Blanking.
• PIP: contains the set ups for Picture in Picture.
15.1 Entering the Random Access Mode menu
How to enter the Random Access Mode
1. From the adjustment mode menu, select item RANDOM ACCESS. (menu 15-1)
The Random Access adjustment mode menu appears on-screen and in the graphical display. (menu 15-2)
2. Press EXIT (RCU) or select item RETURN (ACSAR) to return.
ADJUSTMENT MODE
Select a path from below :
RANDOM ACCESS
INSTALLATION
SERVICE
Select with ↑ or ↓
then
to return
0HQX
RANDOM ACCESS
ADJUSTMENT MODE
FILE SERVICE
IMAGE SETTINGS
PICTURE TUNING
GEOMETRY
PIP
Select with ↑ or ↓
then
to return
0HQX
15.2 Image Settings
Overview
• Adjusting the Analog Image Controls
• Image Fine Tuning
